Fingerprint sensor

SGD 89.00


Availability: This product is no longer in stock

Notify me when available

Secure your project with biometrics - this all-in-one optical fingerprint sensor will make adding fingerprint detection and verification super simple. These modules are typically used in safes - there's a high powered DSP chip that does the image rendering, calculation, feature-finding and searching. Connect to any microcontroller or system with TTL serial, and send packets of data to take photos, detect prints, hash and search. You can also enroll new fingers directly - up to 162 finger prints can be stored in the onboard FLASH memory. There's a red LED in the lens that lights up during a photo so you know its working.

We like this particular sensor because not only is it easy to use, it also comes with fairly straight-forward Windows software that makes testing the module simple - you can even enroll using the software and see an image of the fingerprint on your computer screen. But, of course, we wouldn't leave you a datasheet and a "good luck!" - we wrote a full Arduino library so that you can get running in under 10 minutes. The library can enroll and search so its perfect for any project. We've also written a detailed tutorial on wiring and use. This is by far the best fingerprint sensor you can get.

  • Baud rate 9600, 19200, 28800, 38400, 57600 (default is 57600)
  • Communication Interface TTL Serial
  • Fingerprint imaging time less than 1.0 seconds
  • Remarks Full Dimensions: 56 x 20 x 21.5mm
  • Signature file 256 bytes
  • Storage capacity 162 templates
  • Template file 512 bytes
  • Weight 20g
  • Window area 14mm x 18mm
  • Working humidity 40%-85% RH
  • Working temperature -20C to +50C
